Auto Reset Ceramic KSD301 Thermal Cutout Switch

Auto Reset Ceramic KSD301 Thermal Cutout Switch
Auto Reset Ceramic KSD301 Thermal Cutout Switch Auto Reset Ceramic KSD301 Thermal Cutout Switch Auto Reset Ceramic KSD301 Thermal Cutout Switch Auto Reset Ceramic KSD301 Thermal Cutout Switch Auto Reset Ceramic KSD301 Thermal Cutout Switch

Large Image :  Auto Reset Ceramic KSD301 Thermal Cutout Switch

Product Details:

Place of Origin: DONGGUAN,CHINA
Brand Name: HENGHAO
Certification: UL CQC TUV ROHS
Model Number: KSD301

Payment & Shipping Terms:

Minimum Order Quantity: 1000PCS
Price: US$0.2-0.3 PER PC
Packaging Details: 1650 PCS PER CARTON
Delivery Time: 7-10 WORKING DAYS
Payment Terms: TT FOB SZ
Supply Ability: 1000000PCS PER MONTH
Detailed Product Description
Product Name: KSD301 Thermal Cutout Switch Voltage & Current: 250V 10-16A
Temp. Range: 0-300 Degree Case: Plastic Or Ceramic
Type: Anto-reset Type Voltage: 12/24VDC
High Light:

KSD301 Thermal Cutout Switch

,

Ceramic Thermal Cutout Switch

,

Auto Reset Bimetal Disc Thermostats

Ceramic KSD301 Thermal Cutout Switch , Bimetal Disc Thermostats KSD301 thermall switch with UL CQC TUV ROHS certifiate​



Description



Thermal cutoff devices cut off power as a result of temperature rise. These are often integrated into the body of equipment to protect against overheating.

Technically, an bimetal thermostat is also a type of thermal cutoff device because when it blows it opens the connection to power. However, industry excludes this ordinary fuse from the list of temperature cutoff devices because thermal fuses are slightly more sophisticated. They consist of a spring held tight mechanically at one end and soldered at the other end to an alloy. If the equipment heats beyond the desired temperature, the solder melts and releases the spring to interrupt power. The temperature of operation depends on the alloy. This process is an example of one-time use thermal cutoff devices.



Specification



Item
Bimetal Bent Terminal Momentary KSD301 Thermostat 16A 125V
Material
Bakelite
Terminal Size
6.35x0.8MM
Housing Color
Silver
Working Temperature
0 ℃- 260 ℃
Circuit Resistance
50 Ω Max
Operating Life
10000 Cycles
OEM or ODM
Available ksd301 thermostat 16a 125v




Auto Reset Ceramic KSD301 Thermal Cutout Switch 0

Auto Reset Ceramic KSD301 Thermal Cutout Switch 1



Open temperature & reset temperature



1.     According to customer’s request to set the open temperature and reset temperature.

2.     The standard open temperature and reset temperature’s sheet for auto reset type as below



Open Temp.

Reset Temp.

Open Temp.

Reset Temp.

Open Temp.

Reset Temp.

-20℃+-5℃

5℃+-5℃

95℃+-5℃

80℃+-5℃

205℃+-5℃

175℃+-10℃

-15℃+-5℃

5℃+-5℃

100℃+-5℃

80℃+-10℃

210℃+-5℃

180℃+-10℃

-10℃+-5℃

5℃+-5℃

105℃+-5℃

85℃+-10℃

215℃+-5℃

185℃+-10℃

0℃+-5℃

-10℃+-5℃

110℃+-5℃

90℃+-10℃

220℃+-5℃

190℃+-10℃

5℃+-5℃

-5℃+-5℃

115℃+-5℃

95℃+-10℃

225℃+-5℃

195℃+-10℃

10℃+-5℃

0℃+-5℃

120℃+-5℃

100℃+-10℃

230℃+-5℃

200℃+-10℃

15℃+-5℃

5℃+-5℃

125℃+-5℃

105℃+-10℃

235℃+-5℃

205℃+-10℃

20℃+-5℃

5℃+-5℃

130℃+-5℃

110℃+-10℃

240℃+-5℃

210℃+-10℃

25℃+-5℃

10℃+-5℃

135℃+-5℃

115℃+-10℃

245℃+-5℃

215℃+-10℃

30℃+-5℃

15℃+-5℃

140℃+-5℃

120℃+-10℃

250℃+-5℃

220℃+-10℃

35℃+-5℃

20℃+-5℃

145℃+-5℃

125℃+-10℃

255℃+-5℃

225℃+-10℃

40℃+-5℃

25℃+-5℃

150℃+-5℃

130℃+-10℃

260℃+-5℃

230℃+-10℃

45℃+-5℃

30℃+-5℃

155℃+-5℃

130℃+-10℃

265℃+-5℃

235℃+-10℃

50℃+-5℃

35℃+-5℃

160℃+-5℃

135℃+-10℃

270℃+-5℃

240℃+-10℃

55℃+-5℃

40℃+-5℃

165℃+-5℃

140℃+-10℃

275℃+-5℃

245℃+-10℃

60℃+-5℃

45℃+-5℃

170℃+-5℃

145℃+-10℃

280℃+-5℃

250℃+-10℃

65℃+-5℃

50℃+-5℃

175℃+-5℃

150℃+-10℃

285℃+-5℃

255℃+-10℃

70℃+-5℃

55℃+-5℃

180℃+-5℃

155℃+-10℃

290℃+-5℃

260℃+-10℃

75℃+-5℃

60℃+-5℃

185℃+-5℃

155℃+-10℃

295℃+-5℃

265℃+-10℃

80℃+-5℃

65℃+-5℃

190℃+-5℃

160℃+-10℃

300℃+-5℃

270℃+-10℃



The product UL,CQC,VDE and RoHS certification approval.
