17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A

17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A
17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A
17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A 17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A 17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A 17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A 17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A 17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A 17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A 17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A

Large Image :  17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A

Product Details:
Place of Origin: CHINA
Brand Name: HENG HAO
Certification: UL TUV CQC
Model Number: 17AM
Payment & Shipping Terms:
Minimum Order Quantity: 1000pcs
Price: USD
Packaging Details: 5000pcs per carton
Delivery Time: 10WORKDAYS
Payment Terms: TT FOB SZ,T/T
Supply Ability: 10000000pcs per month
Contact Now

17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A

Description
Rating And Currents:: AC-125V 15A; AC-250V 10A, DC-16V 20A Life Time: 10000 Times
Use For: 17AM Thermal Protector Is Applicable To All Kinds Of Motor, Commentator For Fluorescent Lamp, Transformer, Laminator, Lamps And Lighting, Transformers, Cover Sealing Machine & Various Of Household Appliances Switch Type: Auto Reset Normally Closed Type
Name: Thermal Overload Protection Switch Operating Temperature Range: 50-180°C
Highlight:

17AM023A5 Temperature Protector Thermostat

,

17am032a5 temperature controller

,

17AM Temperature Protector Thermostat

17AM023A5 Temperature Protector Thermostat
The 17AM series is an excess-current thermal protector with compact design, offering quick and accurate action. We can customize different types of leads according to customer requirements.
17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A 0
Product Specifications
  • Electrical Rating: AC-125V 15A; AC-250V 10A, DC-16V 20A
  • Contact Life Cycles:
    • AC-125V 15A, AC-250V 10A: >10,000 cycles
    • AC-125V 5A: >100,000 cycles
  • Operating Temperature Range: 50-180°C
  • Temperature Tolerance: ±2°C/±3°C/±5°C
  • Reset Temperature: 10-45°C below trip temperature
  • Working Times: Over 10,000 operations
Product Code System
17AM_XXX_A/B_5_A,B,C,D...Z
  • 17AMH: Product series number
  • XXX: Trip temperature in °C code
  • A/B: Terminal direction (A: same, B: opposite)
  • 5: OFF temperature tolerance code
  • A-Z: Different connecting wire types
Trip Temperature Code Reference
Degrees °C Code Degrees °C Code Degrees °C Code Degrees °C Code
55°C 018 90°C 025 125°C 032 160°C 039
60°C 019 95°C 026 130°C 033 165°C 040
65°C 020 100°C 027 135°C 034 170°C 041
70°C 021 105°C 028 140°C 035 175°C 042
75°C 022 110°C 029 145°C 036 180°C 043
80°C 023 115°C 030 150°C 037
85°C 024 120°C 031 155°C 038
Product Functionality
The thermal protection switch is typically located on A/C compressor housings to prevent compressor damage from overheating caused by internal friction. It senses compressor case temperature and interrupts the electrical circuit when a predetermined temperature threshold is reached.
17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A 1
Protection Mechanism
The thermal protection switch safeguards against overload conditions. This is achieved through a design where motor current passes through a small heater winding within a brass tube assembly.
Product Drawings
17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A 2 17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A 3
Applications
Suitable for various applications including:
  • Motors and compressors
  • Fluorescent lamp ballasts
  • Transformers
  • Laminators
  • Lighting systems
  • Cover sealing machines
  • Household appliances
17AM023A5 Temperature Protector Thermostat with 50-180°C Operating Range AC-250V 10A DC-16V 20A 4
Compatibility: Can be used as a replacement for KLIXON 17AM thermal protectors.
