BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection

BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection
BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection
BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection

Large Image :  BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection

Product Details:
Place of Origin: CHINA
Brand Name: HENGHAO
Certification: UL TUV CQC KC
Model Number: BW-ABS
Payment & Shipping Terms:
Minimum Order Quantity: 10000PCS
Price: USD 0.15~0.3PCS
Packaging Details: 2000PCS
Delivery Time: 10~15PCS
Payment Terms: T/T
Supply Ability: 1000000PCS
Contact Now

BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection

Description
Life Cycle: 100000 Cycles Voltage & Current: 250V 10A
Contact Type: Normally Closed Or Normally Open Switch Type: Auto Reset Or Manual Rese
Temperature Range: 50-150℃ Case: Plastic
Highlight:

ST-22 SEKI Thermostat

,

9700K Temperature Switch

,

BW-ABJ Temperature Switch

BW-ABJ KSD9700 Temperature Controller ST-22 SEKI Thermostat 9700K Temperature Switch
The BW & BH series temperature controllers provide reliable protection against over-current and over-temperature conditions. These sealed units feature small internal resistance, operate silently, and reset automatically. The bimetal components respond to both temperature and current changes, cutting off or restoring the circuit as needed.
BH Series Thermostat Specifications
Electrical Rating DC-12V max 12A; DC-24V max 10A; AC-125V max 8A; AC-250V max 16A
Open temperature (30~150)±5°C; 5°C a step
Reset temperature 2/3 of the action temperature with tolerance of ±15°C. Custom reset temperatures available.
Life times 10000 times
Size L15mm W7.1mm H3.8mm
Lead wire #22 3266, end half tripping, length is 70mm, or customized
Certifications UL File no: E487478
CQC certificate no: CQC16002142880
TUV certificate no: B160592241002
BH Series Dimensions
Model Case Length(mm) Width(mm) Height(mm) Voltage & Current Lead wire
H20 Plastic 18.5 8 4 DC-12V max 12A; DC-24V max 10A; AC-125V max 8A; AC-250V max 10A #20 3135, end 5mm half tripping, length 70mm, or customized
H21 Metal 18.5 7.3 3.8
H21 Metal 20 8 4 AC250V 20A #16 3135
BH-A1D Metal 15 6.6 3.2 DC-12V max 12A; DC-24V max 10A; AC-125V max 8A; AC-250V #20 3135, #22 3266,#22 3135, end 5mm half tripping, length 70mm, or customized
BH-B2D Plastic 15 7.1 3.8
BH-TB02B-B8D Plastic 15 5.2 2.4 DC-12V max 4A; DC-24V max 3A; AC-125V max 3A; AC-250V max 2A 3266-AWG24#, 3135-AWG24# or nickel strip, length 70mm or customized
BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection 0
BH Series Applications
These reliable thermal protectors are widely used in:
  • 1.5 horsepower motors
  • Lighting devices
  • Inverter welding machines
  • Switch power supplies
  • Rechargeable battery packs
  • Fluorescent lamp ballasts
  • Portable power tools
  • Various electric appliances
Enforced types can withstand pressure of 3.5MPa for build-in installation in plastic coated motors.
Temperature Code Reference
Code Temperature Code Temperature
30 30℃ 100 100℃
35 35℃ 105 105℃
40 40℃ 110 110℃
45 45℃ 115 115℃
50 50℃ 120 120℃
55 55℃ 125 125℃
60 60℃ 130 130℃
70 70℃ 135 135℃
75 75℃ 140 140℃
80 80℃ 145 145℃
85 85℃ 150 150℃
90 90℃
H20/H21 Series Thermal Protectors
These universal protectors feature large metal casings with bimetallic components that respond to temperature changes. When abnormal conditions occur, the contact points open to disconnect the circuit, automatically resetting when temperatures return to safe levels.
H20/H21 Series Specifications
Electrical Rating DC-12V max 12A; DC-24V max 10A; AC-125V max 8A; AC-250V max 16A
Open temperature (30~150)±5°C; 5°C a step
Reset temperature 2/3 of the action temperature with tolerance of ±15°C
Life times 10000 times
Contact Closure resistance ≤50mΩ
Insulation resistance ≥100mΩ
Electric strength AC1500V/1min free from phenomena of break down and flashover
Certifications UL File no: E487478
CQC certificate no: CQC16002142880
TUV certificate no: B160592241002
H20/H21 Series Applications
Ideal for use in:
  • Rechargeable batteries
  • Ballasts
  • Massagers
  • Micro motors
  • Transformers
  • Electric tools
  • Heat electric appliances
  • Various instruments
BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection 1 BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection 2 BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection 3 BW-ABJ KSD9700 Temperature Controller Thermostat with 50-150℃ Range Plastic Case and Over-Current Protection 4
Certifications: UL, CQC, TUV and RoHS compliant
