High Precision NTC Thermistor Temperature Sensor with 500Ω~5MΩ Resistance Range and 2500~5000K Material Coefficient

Large Image : High Precision NTC Thermistor Temperature Sensor with 500Ω~5MΩ Resistance Range and 2500~5000K Material Coefficient

Product Details:

Place of Origin:	China
Brand Name:	HENG HAO
Model Number:	NTC Thermistor

Payment & Shipping Terms:

Minimum Order Quantity:	5000
Price:	$0.18-0.25

Contact Now

High Precision NTC Thermistor Temperature Sensor with 500Ω~5MΩ Resistance Range and 2500~5000K Material Coefficient

Description

Operating Temperature:	-40℃~+120℃	Nominal Resistance:	500Ω~5MΩ
Resistance Tolerance:	±1,±2, ±3, ±5, ±10	Material Coefficient:	2500~5000K
Thermal Time Constant:	≤25S	Dissipation Coefficient:	≥0.8mw/℃
Rated Power:	50mw	Package Type:	Surface Mount
Technology:	Metal Alloy	B25/50 Value:	±1,±2
Constant Temperature:	25℃±0.05℃	Thermal Sensitivity:	Constant Temperature 50℃±0.05℃
Working Temperature:	-40℃~+120℃	Resistance Range:	500Ω~5MΩ
Power Rating:	50mw
Highlight:	500Ω~5MΩ NTC Thermistor , 2500~5000K Temperature Sensor , ±1 , ±2 , ±3 , ±5 , ±10 Thermal Resistor

Wholesale China High Quality Hot Water Heater NTC Thermistor Sensor Constant Temperature For Induction Cooker

Product Specifications

Parameter	Specifications
R25 (Nominal Resistance Value)	500Ω~5MΩ, Constant temperature 25℃±0.05℃
R25 Permissible Variance (%)	±1, ±2, ±3, ±5, ±10, Constant temperature 25℃±0.05℃
B25/50 (Material Coefficient / Thermal-Sensitivity Index)	2500~5000K, Constant temperature 25℃±0.05℃, Constant temperature 50℃±0.05℃
B25/50 Value Permissible Variance (%)	±1, ±2, Constant temperature 25℃±0.05℃, Constant temperature 50℃±0.05℃
∫ (Dissipation Coefficient)	≥0.8mw/℃, Static in the air
T (Thermal Time Constant)	≤25S, Static in the air
Ta (Working Temperature)	-40℃~+120℃
Pn (Rated Power)	50mw, within working temperature
