High Current NTC Thermistor Temperature Sensor with Operating Temperature -40℃~+120℃ and R25 500Ω~5MΩ for Disinfecting Cabinet

Large Image : High Current NTC Thermistor Temperature Sensor with Operating Temperature -40℃~+120℃ and R25 500Ω~5MΩ for Disinfecting Cabinet

Product Details:

Place of Origin:	China
Brand Name:	HENG HAO
Model Number:	NTC Thermistor

Payment & Shipping Terms:

Minimum Order Quantity:	5000
Price:	$0.18-0.25

Contact Now

High Current NTC Thermistor Temperature Sensor with Operating Temperature -40℃~+120℃ and R25 500Ω~5MΩ for Disinfecting Cabinet

Description

Operating Temperature:	-40℃~+120℃	Nominal Resistance:	500Ω~5MΩ
Resistance Tolerance:	±1,±2, ±3, ±5, ±10	Material Coefficient:	2500~5000K
Thermal Sensitivity:	Constant Temperature 50℃±0.05℃	Dissipation Coefficient:	≥0.8mw/℃
Thermal Time Constant:	≤25S	Rated Power:	50mw
Package Type:	Surface Mount	Technology:	Metal Alloy
Resistance Range:	500Ω~5MΩ	B25/50 Tolerance:	±1,±2
Static Air Condition:	Static In The Air	Working Temperature:	-40℃~+120℃
Thermal Resistor Type:	NTC Thermistor
Highlight:	High Current NTC Thermistor , Operating Temperature -40℃~+120℃ Temperature Sensor , R25 500Ω~5MΩ Thermal Resistor

Factory Supplier Price High Current NTC Temperature Sensor Thermistor SMD For Disinfecting Cabinet

Product Specifications

Parameter	Specification
R25 (Nominal Resistance Value)	500Ω~5MΩ, Constant temperature 25℃±0.05℃
R25 Permissible Variance (%)	±1, ±2, ±3, ±5, ±10, Constant temperature 25℃±0.05℃
B25/50 (Material Coefficient / Thermal Sensitivity Index)	2500~5000K, Constant temperature 25℃±0.05℃, Constant temperature 50℃±0.05℃
B25/50 Value Permissible Variance (%)	±1, ±2, Constant temperature 25℃±0.05℃, Constant temperature 50℃±0.05℃
∫ (Dissipation Coefficient)	≥0.8mw/℃, Static in the air
T (Thermal Time Constant)	≤25S, Static in the air
Ta (Working Temperature)	-40℃~+120℃
Pn (Rated Power)	50mw, within working temperature
