Thermal Limited Switch Thermostat for Transformer 17am023A5 Temperature Protector

Thermal Limited Switch Thermostat for Transformer 17am023A5 Temperature Protector
Thermal Limited Switch Thermostat for Transformer 17am023A5 Temperature Protector Thermal Limited Switch Thermostat for Transformer 17am023A5 Temperature Protector Thermal Limited Switch Thermostat for Transformer 17am023A5 Temperature Protector Thermal Limited Switch Thermostat for Transformer 17am023A5 Temperature Protector Thermal Limited Switch Thermostat for Transformer 17am023A5 Temperature Protector

Large Image :  Thermal Limited Switch Thermostat for Transformer 17am023A5 Temperature Protector

Product Details: Payment & Shipping Terms:
Minimum Order Quantity: 1,000
Price: 0.35
Contact Now

Thermal Limited Switch Thermostat for Transformer 17am023A5 Temperature Protector

Description
Model NO.: 17AMH Material: Steel Plastic
Life Cycle: 10000 Times Voltage: 250V
Current: 10A Temperature Range: 50-180°C
Contact Type: Normally Closed Case: Metal
AC Voltage: 125V AC Current: 15A
DC Voltage: 16V DC Current: 20A
Temperature Tolerance: ±2°C±3°C±5°C Reset Temperature: 10~45°C
Working Times: Over 10000 Times
Highlight:

Thermal protector switch for transformer

,

17am023A5 temperature protector

,

Thermal limited switch thermostat

Thermal Limited Switch Thermostat for Transformer 17AM023A5 Temperature Protector
17AMH Thermal Protector / 17AMH Thermostat / 17AM Temperature Protector / KLIXON 17AM Thermal Protector Replacement
Product Overview
The 17AM is an excess-current thermal protector featuring compact design with quick and accurate action. We can rivet different types of leads according to customers' specific requirements.
Technical Specifications
  • Electrical Rating and Currents: AC-125V 15A; AC-250V 10A, DC-16V 20A
  • Contact Life Cycles: AC-125V 15A, AC-250V 10A: >10,000 cycles; AC-125V 5A: >100,000 cycles
  • Operating Temperature Range: 50-180°C
  • Temperature Tolerance: ±2°C, ±3°C, ±5°C
  • Reset Temperature: 10-45°C below trip temperature
  • Working Times: Over 10,000 operations
Product Coding System
17AM_XXX_A/B_5_A,B,C,D...Z
  • 17AMH: Product series number
  • XXX: Trip off temperature in °C code
  • A/B: A: Terminals in same direction / B: Terminals in opposite direction
  • 5: OFF temperature tolerance code
  • A,B,C,D...Z: Different types of connecting wire
Temperature Code Reference
Degrees °C Code Degrees °C Code Degrees °C Code Degrees °C Code
55°C 018 90°C 025 125°C 032 160°C 039
60°C 019 95°C 026 130°C 033 165°C 040
65°C 020 100°C 027 135°C 034 170°C 041
70°C 021 105°C 028 140°C 035 175°C 042
75°C 022 110°C 029 145°C 036 180°C 043
80°C 023 115°C 030 150°C 037
85°C 024 120°C 031 155°C 038
Applications
The 17AM thermal protector is suitable for various applications including motors, fluorescent lamp commutators, transformers, laminators, lighting systems, cover sealing machines, and various household appliances.
Product Images
Thermal Limited Switch Thermostat for Transformer 17am023A5 Temperature Protector 0 Thermal Limited Switch Thermostat for Transformer 17am023A5 Temperature Protector 1 Thermal Limited Switch Thermostat for Transformer 17am023A5 Temperature Protector 2 Thermal Limited Switch Thermostat for Transformer 17am023A5 Temperature Protector 3 Thermal Limited Switch Thermostat for Transformer 17am023A5 Temperature Protector 4 Thermal Limited Switch Thermostat for Transformer 17am023A5 Temperature Protector 5
This product has UL, CQC, VDE and RoHS certification approval.
